Description
- IDEAL FOR PRINTING COLOUR LABELS , TAGS , TICKETS (Print Colour On-Demand)- Epson Printhead Technology – PrecisionCore , Mechnical method to eject consistant Ink Droplets. Precisely control volume of ink contained in each ink droplet, 4-inch Colour Label On-Demand Printer. 4 colours Pigment Ink, astounding print quality of 1200dpi. Peel & present function for individual print jobs.
- Enhanced Production Capability – The C6050P’s peel-and-present model improves efficiency and convenience by eliminating the need for manual peeling. When integrated with a print-and-apply system through the use of label applicators, a more seamless workflow experience is enabled, enhancing productivity in the production line.
- Crisp Images – A higher dpi translates to a clearer, more detailed output. With a print resolution of up to 1200 dpi, variable droplet size and Spot Colour Matching* that assures greater colour accuracy, the C6050P ColorWorks label printers series produce incredible print images.
- High Connectivity – Compatible with a wide range of technologies including multiplatform operating systems such as Windows, Mac and Linux along with application software including SAP and legacy systems using ZPL II commands, the set-up process becomes effortless and can be integrated into nearly any workflow seamlessly.
- World’s First Peeler-equipped Inkjet Label Printer – Making it possible to apply labels immediately after printing, the C6050P can be used in any desktop printing operations. When integrated with a label applicator in the production floor, it offers unique print-and-apply system that can be used both online and offline.
- Easy Use and Maintenance– Intuitive designs including easy-load spindle, flexible paper cover and frontal ink cartridge loading allows for quick changes between label sizes, easy access when loading paper and effortless replacement of ink cartridges. Equipped with a 2.7” colour LCD, printer status can be checked and configured when required. Enjoy seamless installation in a variety of environments with the ColorWorks’ space-saving design.
- Durable, Exceptional Quality Inks – The ColorWorks C6000 series incorporates UltraChrome DL pigment inks that comply with BS 5609 certification for GHS compliant labelling. These inks possess high pigment density, resin coating for more stability, and an even surface and gloss, making it perfect for professional display and sales.
- PrecisionCore TFP Printhead– With its stunning ability to scale while delivering unbeatable speed and precision, the printhead’s perfectly round nozzles dispense precise ink droplets, which guarantee consistent superior image quality.
Printing Technology:
- Print Speeds: Matte Paper Label, Synthetic Label: Max Speed (300 x 600 dpi): 119mm/s, Speed (600 x 600 dpi): 75mm/s, Normal (600 x 600 dpi): 48mm/s, Quality (600 x 1200 dpi): 18mm/s
*When printing 101.6mm width. Glossy Paper Label, Glossy Film Label, High Glossy Paper Label .Normal (600 x 600 dpi): 48mm/s, Quality (600 x 1200 dpi): 18mm/s, Max quality (1200 x 1200 dpi): 8mm/s. *When printing 101.6mm widthTechnolgy: Serial Inkjet PrecisionCore TFP® with Nozzle Verification TechnologyColour: Four-colour printing, individual ink cartridge (UltraChromeTM DL pigment ink: C, M, Y, K) - Ink Cartridge: Colour: Black, Cyan, Magenta, Yellow | Model: SJIC40P-BK / SJIC40P-C / SJIC40P-M / SJIC40P-Y / SJIC40P-MK
- Print Resolution: 1200 x 1200 dpi (max.) | Max. Print Width: 108mm
- Connectivity Interface: USB2.0, Ethernet 1000Base-T / 100Base-TX / 10Base-T / Extended Interface: Dsub-25pin
- Print Fonts: Built-in font available
- Barcode Font (Printer Driver Built-in): UPC-A, UPC-E, JAN13(EAN), JAN8(EAN), Code39, ITF, Codabar, Code93, Code128, GS1-128, GS1 DataBar, Omnidirectional, GS1 DataBar Truncated, GS1 DataBar Limited, GS1 DataBar Expanded | Two-dimensional Code: PDF417, QR Code, Maxi Code, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1 DataBar, Expanded Stacked, DataMatrix, Aztec Code, MicroPDF417, Micro QR Code
- Media Source: Roll media, Fanfold
- Media Type: Matte paper label, Synthetic label, Glossy paper label, Glossy film label, High glossy paper label
- Media Form: Roll: Continuous label (BM or w/o BM), Die-cut label (Gap or BM) | Fanfold: Die-cut label (BM)
- Paper Specifications: Number Of Folds: 750 or Less | Winding Direction: Face Out
- Temperature / Humidity: Printing: Printing: 5 to 35°C / 20 to 80% RH Barcode Printing: 15 to 35°C, 20 to 80% RH | Storage: When packed (ink not charged): -20 to 60°C / 5 to 85% RH Humidity (no condensation)
- Overall Dimensions: 340 x 565 x 326mm (W x D x H, not including protrusion) | Mass: Approx. 22.8kg
- Power Supply: Built-in Power Supply
- Power Consumption: Operating: 100V: Average approximately 39.4W | 230V: Average approximately 38.6W | Standby: 100V: Average approximately 7.51W | 230V: Average approximately 5.82W | Power Off: 100V: Average approximately 0.08W | 230V: Average approximately 0.24W | Rated Voltage: 100 – 240VAC | Rated Frequency: 50 – 60Hz
- EMC Standards: Europe: CE Marking | North America: FCC Class A, CAN ICES-3 (A)/NMB-3 (A) | Oceania: Radiocommunications (Electromagnetic Compatibility) Standard, Class A
- Operating System: Windows 10, 8.1, 8, 7 SP1, Vista SP2, XP SP3 or later, Server 2019, 2016, 2012 R2, 2012, 2008 R2, 2008, 2003 R2 (32-bit), Mac OS X 10.6.8, Mac OS X 10.7.x, Mac OS X 10.8.x, Mac OS X 10.9.x, Mac OS X 10.10.x, Mac OS X 10.11.x, Mac OS X 10.12.x, Mac OS X 10.13.x, Mac OS X 10.14.x
- Printer Details:
- Options: Paper Holder C6000 (for C6050 Series)
- Media Handling: Width: Backing Paper Width: 25.4 to 112mm , Label Width: 21.4 to 108mm | Thickness: Matt paper label: 0.178mm , Synthetic label: 0.235mm, Glossy paper label: 0.174mm, Glossy film label: 0.164mm | High glossy paper label: 0.188mm
- Roll Diameter: Max. 203.2mm | Core Diameter: Inner: 76.2 mm ± 0.5 mm | Die-cut Label Gap: 2 to 6mm (if the gap is 3mm or less, need to adjust the detector) | Black Mark Size: Width: 18.4mm or over | Length: 4 to 25.4mm
